Core Features

• One-metre cut interval — optimised for long uninterrupted runs — parapets, fascias, and continuous rooflines where the coarse pitch wastes nothing because the run length is a multiple of a metre.
• Two white channels in one body — warm and cool wired separately in a single 11.5 × 6.5 mm profile, replacing two installed runs and two sets of fixings.
• 620 lm/m at 7 W — the lower-power dual white option — against 900 lm/m at 9 W on the other dual white model with the same body size; choose on whether the line is decorative or functional.
• Operates directly on AC 220–240 V mains — no transformer and no low-voltage distribution, at 0.043 A per metre.
• 50 m per reel — a practical reel size for projects made up of several long runs rather than one continuous one.
• IP65 PVC body for sheltered outdoor use — sealed against dust and water jets; not for submersion or standing water.
• Energy efficiency class F — better than the class G rating on the lowest-output models in the range.
• CE / RoHS certified — note that CB is not held for this model; the 900 lm/m dual white model in the range does carry CB.

Application Scenarios

• Long continuous rooflines and parapets — the core use case; the coarse cut interval is irrelevant when runs are measured in tens of metres.
• Perimeter outlining on large footprints — warehouses, logistics buildings, and industrial units with long unbroken elevations.
• Decorative outline with day and evening modes — dual white gives two colour temperatures from one run where output demands are modest.
• Boundary and fence line lighting — long straight runs where fine length matching adds nothing.
• Hospitality exteriors with extended terraces — one line covering long elevations, switched warm or cool by time of day.
• Budget-sensitive facade schemes — lower power and lower output where the outline is decorative rather than a lighting source.

Technical Specifications

• Model No. — JNL-W-220V-2835-0120-08-S1XX
• Item No. — To be confirmed (please quote the model code above when enquiring)
• LED type — 2835 SMD (3 V, 18–20 lm)
• LED quantity — 120 PCS/m (dual white)
• Rated voltage — AC 220 V
• Input voltage range — AC 200–240 V
• Rated frequency — 50/60 Hz
• Input frequency range — 47–63 Hz
• Rated power — 7 W/m ± 10%
• Input current — 0.043 A @ 1m
• Power factor — > 0.9
• Luminous flux — 620 lm/m
• Colour temperature — Dual white; the datasheet field carries the standard 2700–6500 K template entry, so confirm the exact warm/cool pairing with our engineering team at order
• Colour rendering index — Ra 70
• SDCM — ≤ 7
• Beam angle — 120°
• Lumen maintenance — L80B20 @ 20,000 h
• Energy efficiency class — F
• Ingress protection — IP65 (sheltered outdoor use; not for submersion)
• Outline dimensions — W11.5 × H6.5 ± 0.5 mm
• Surface material — PVC
• Cut length — 1000 mm
• Mounting method — Fixed with buckle and screws
• Dimming method — Turn on the power and it lights up; warm and cool channels switch independently
• Switching cycles — 15,000 times
• Operating temperature — -25°C to +45°C
• Storage temperature — -40°C to +60°C
• Relative humidity — 10–90%
• MTBF — 20,000 h
• Mains compatibility — AC 200–240 V, 50/60 Hz; not suitable for 120 V residential supply
• Packing — Reel + Carton
• Packing quantity — 50 m/reel
• Certification — CE / RoHS (CB not held for this model)
